FEATURES

• Designed and qualified according to

JEDEC®-JESD 47

• Low IGT parts available

• 125 °C max. operating junction temperature

• Material categorization

for definitions of compliance please see

APPLICATIONS
• Typical usage is in input rectification crowbar (soft start) and AC switch motor control, UPS, welding and battery charge

DESCRIPTION

The VS-40TPS... high voltage series of silicon controlled rectifiers are specifically designed for medium power switching and phase control applications. The glass passivation technology used has reliable operation up to 125 °C junction temperature.
