Features:

• Zener Voltage Range − 3.3 V to 200 V

• ESD Rating of Class 3 (> 16 kV) per Human Body Model

• Flat Handling Surface for Accurate Placement

• Package Design for Top Side or Bottom Circuit Board Mounting

• AEC−Q101 Qualified and PPAP Capable − SZ1SMB59xxT3G

• SZ Prefix for Automotive and Other Applications Requiring Unique

Site and Control Change Requirements

• These are Pb−Free Devices*

Mechanical Characteristics:

CASE: Void-free, transfer-molded plastic

FINISH: All external surfaces are corrosion resistant and leads are

readily solderable

MAXIMUM LEAD TEMPERATURE FOR SOLDERING PURPOSES:

260°C for 10 Seconds

LEADS: Modified L−Bend providing more contact area to bond pads

POLARITY: Cathode indicated by polarity band

FLAMMABILITY RATING: UL 94 V−0
