NXP

PDZ6.8B

Pd-power dissipation: 400 mW

Voltage tolerance: 2%

Voltage temperature coefficient: 3.4 mV/K

Zener current: 500 nA

Zz-Zener impedance: 40 Ohms

Minimum working temperature: 0 C

Maximum working temperature: + 150 C

Configuration: Single

Test current: 5 mA

Height: 0.95 mm

Ir-Reverse current: 500 nA

Length: 1.7 mm

General description

Low-power general purpose voltage regulator diodes in a small plastic SMD SOD323 (SC-76)package.

Features and benefits

• Total power dissipation: Ptot ≤ 400 mW

• Small plastic package suitable for surface mounted design

• Wide variety of voltage ranges: nominal 2.4 V to 36 V (E24 range)

• Tolerance approximately ± 2 %

Applications

General voltage regulation
