PRoC™ LP Features
■ USB 2.0-USB-IF certified (TID # 40000552)
■ Single Device, Two Functions
❐ 8-bit, Flash based USB peripheral MCU function and 2.4 GHz
radio transceiver function in a single device
■ Flash Based Microcontroller Function
❐ M8C based 8-bit CPU, optimized for Human Interface
Devices (HID) applications
❐ 256 bytes of SRAM
❐ 8 Kbytes of Flash memory with EEPROM emulation
❐ In-System reprogrammable through D+/D– pins
❐ 16-bit free running timer
❐ Low power wake up timer
❐ 12-bit Programmable Interval Timer with interrupts
❐ Watchdog timer
■ Industry-Leading 2.4 GHz Radio Transceiver Function
❐ Operates in the unlicensed worldwide Industrial, Scientific
and Medical (ISM) band (2.4 GHz to 2.483 GHz)
❐ DSSS data rates of up to 250 Kbps
❐ GFSK data rate of 1 Mbps
❐ –97 dBm receive sensitivity
❐ Programmable output power of up to +4 dBm
❐ Auto Transaction Sequencer (ATS)
❐ Framing CRC and Auto ACK
❐ Received Signal Strength Indication (RSSI)
❐ Automatic Gain Control (AGC)
■ Component Reduction
❐ Integrated 3.3 V regulator
❐ Integrated pull up on D–
❐ GPIOs that require no external components
❐ Operates off a single crystal
■ Flexible I/O
❐ 2 mA source current on all GPIO pins. Configurable 8 mA or
50 mA/pin current sink on designated pins
❐ Each GPIO pin supports high impedance inputs, configurable
pull up, open-drain output, CMOS/TTL inputs and CMOS
output
❐ Maskable interrupts on all I/O pins
■ USB Specification Compliance
❐ Conforms to USB Specification Version 2.0
❐ Conforms to USB HID Specification Version 1.1
❐ Supports one Low Speed USB device address
❐ Supports one control endpoint and two data end points
❐ Integrated USB Transceiver
■ Operating Voltage from 4.0 V to 5.5 V DC
■ Operating Temperature from 0 to 70C
■ Pb-free 40-pin QFN Package
■ Advanced Development Tools Based on Cypress’s PSoC®
Tools
Applications
The CYRF69213 PRoC LP Low Speed is targeted for the
following applications:
■ USB Bridge for Human Interface Devices (HID)
❐ Wireless mice
❐ Wireless keyboards
❐ Remote controls
❐ Gaming applications
■ USB Bridge for General Purpose Applications
❐ Consumer electronics
❐ Industrial applications
❐ White goods
❐ Home automation
❐ Personal health
Functional Description
PRoC LP devices are integrated radio and microcontroller
functions in the same package to provide a dual role single-chip
solution.
Communication between the microcontroller and the radio is via
the SPI interface between both functions.
