Features

 Low conduction and reverse losses

 Negligible switching losses

 Low forward and reverse recovery times

 Extremely fast switching

 Surface mount device

 Low capacitance diode

 ECOPACK®2 compliant component

Description

The BAT54 series uses 40 V Schottky barrier

diodes packaged in SO123, SOD323, SOD523,

SOT-23, or SOT-323.
