Features

• Available in 5-Lead SC-70 and 5-Lead SOT-23

Packages

• Gain Bandwidth Product: 1 MHz (typical)

• Rail-to-Rail Input/Output

• Supply Voltage: 1.8V to 6.0V

• Supply Current: IQ = 100 µA (typical)

• Phase Margin: 90° (typical)

• Temperature Range:

- Industrial: -40°C to +85°C

- Extended: -40°C to +125°C

• Available in Single, Dual and Quad Packages

Applications

• Automotive

• Portable Equipment

• Photodiode Amplifier

• Analog Filters

• Notebooks and PDAs

• Battery-Powered Systems

Design Aids

• SPICE Macro Models

• FilterLab® Software

• Mindi™ Circuit Designer and Analog Simulator

• Microchip Advanced Part Selector (MAPS)

• Analog Demonstration and Evaluation Boards

• Application Notes

Description

The Microchip Technology Inc. MCP6001/2/4 family of

operational amplifiers (op amps) is specifically

designed for general purpose applications. This family

has a 1 MHz Gain Bandwidth Product (GBWP) and 90°

phase margin (typical). It also maintains a 45° phase

margin (typical) with a 500 pF capacitive load. This

family operates from a single-supply voltage as low as

1.8V, while drawing 100 µA (typical) quiescent current.

Additionally, the MCP6001/2/4 supports rail-to-rail input

and output swing, with a Common-mode input voltage

range of VDD + 300 mV to VSS – 300 mV. This family of

op amps is designed with Microchip’s advanced CMOS

process.

The MCP6001/2/4 family is available in the industrial

and extended temperature ranges, with a power supply

range of 1.8V to 6.0V.
